Advantages of UV electronic ballasts compared to inductive ballasts

Advantages of UV electronic ballasts compared to inductive ballasts:



1) Energy saving. The UV electronic ballast of UV lamp uses more 20-60khz frequency to supply the lamp, so that the light efficiency of the lamp is about 10% higher than the power frequency (according to the length of UV lamp is 4 feet), and its own low power consumption, so that the total input power of the UV lamp is reduced by about 20%, and has better energy saving effect.

2) Eliminate stroboscopic, light more stable. It is beneficial to improve visual resolution and improve efficiency; Reduce the visual fatigue of continuous work and help to protect eyesight

3) More reliable starting point. After preheating UV lamp, one starting point is successful, avoiding multiple starting points.

4) High power factor. Fluorescent lamps above 25W that meet national standards have a power factor higher than 0.95, and inductive ballasts are generally lower than 0. 5

5) Stable input power and output luminous flux: high-quality products have good voltage regulation performance, when the power supply and voltage deviation is very large, it can still maintain the constant power of the light source, stable illuminance, which is conducive to energy saving

6) Prolong the life of the lamp. The constant power and lamp current drop of high-quality products, as well as the reliable starting point and other factors can extend the lamp life.

7) Low noise. The noise of high-quality UV electronic ballasts can reach 35db or less, and people can not feel the noise

8) Can be dimmed. For places that need dimming, such as: the original use of incandescent lamps or halogen tungsten lamps dimming places, instead of high-efficiency fluorescent lamps with adjustable light electronic ballasts, can achieve a wide range of dimming in 2%-100%

9) Can add many additional functions, such as indicator light, buzzer, digital tube, switch quantity and so on.





Post time:2024-10-17
